Conical Accessories

Cube for conical trusses

CUBE

TI-CUBE-M3030-6C.9_145

Adaptor for conical trusses

ADAPTOR

TI-ADAP-M3030-C.9_145

Base plate M3030 for conical trusses

BASE PLATE

BASE-M3030-1414C

Specification
Cubes can be used to make all kinds of structures in a variety of shapes.
Connection
Conical
Dimensions
CC conical 240mm x 240mm
Weight
8 lbs
Material
Aluminum: 6061-T6
Conical: 6061-T6
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
An adaptor is required to be able to use conical cubes with conical trusses.
Connection
Conical
Dimensions
CC conical 240mm
Weight
3 lbs
Material
Aluminum: 6061-T6
Conical: 6061-T6
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
A base plate distribute the load of the truss to the floor and create a counterweight.
Dimensions
14’’ x 14’’ x 3/8’’
Weight
25.3 lbs
Material
Aluminum: 6061-T6
Conical: C12L14
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Conical female for conical elements that have male ends

CONICAL FEMALE

TI-S0001420

Conical male for conical elements that have female ends

CONICAL MALE

TI-S0001267

Conical pin for conical junctions

CONICAL PIN

TI-S0001270

Specification
The conical female (female end) is used as an intermediary to connect conical elements together that have male ends.
Connection
Conical
Weight
0.54 lbs
Material
Aluminum: 6061-T6
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
The conical male (male end) is used as an intermediary to connect conical elements together that have female ends.
Connection
Conical
Weight
0.31 lbs
Material
Aluminum: 6061-T6
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
The conical pin is inserted through the conical junctions (male and female) to keep them connected.
Connection
Conical
Weight
0.09 lbs
Material
Pin: Stressproof 1144
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Threaded pin for conical junctions

THREADED PIN

TI-S0001269

M30 Lifting bracket for trusses

LIFTING BRACKET M30

TI-LB-M30-DC.9

M36 Lifting bracket for trusses

LIFTING BRACKET M36

TI-LB-M36-DC.9

Specification
The threaded pin is inserted through the conical junctions (male and female) to fix them permanently.
Connection
Conical
Weight
0.09 lbs
Material
Pin: Stressproof 1144
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
The lifting bracket clamps on the tubes. It is used to install a fixed point in the structure and eliminate the need for gacflex. Saves space in height.
Dimensions
CC 240mm
Weight
9.13 lbs
Material
Aluminum: 6061-T6
Bolts: Ø5/8” Grade 8
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
Specification
The lifting bracket clamps on the tubes. It is used to install a fixed point in the structure and eliminate the need for gacflex. Saves space in height.
Dimensions
CC 300mm
Weight
10.19 lbs
Material
Aluminum: 6061-T6
Bolts: Ø5/8” Grade 8
Fabricated by
CWB certified welders (AWS equivalent) meets ESTA ANSI E1.2 – 2012
